| Essentials |
| Product Collection |
12th Generation Intel® Core™ i3 Processors |
| Code Name |
Products formerly Alder Lake |
| Vertical Segment |
Desktop |
| Processor Number |
i3-12100 |
| Lithography |
Intel 7 |
| Use Conditions |
PC/Client/Tablet |
| CPU Specifications |
| Total Cores |
4 |
| # of Performance-cores |
4 |
| # of Efficient-cores |
0 |
| Total Threads |
8 |
| Max Turbo Frequency |
4.30 GHz |
| Performance-core Max Turbo Frequency |
4.30 GHz |
| Performance-core Base Frequency |
3.30 GHz |
| Cache |
12 MB Intel® Smart Cache |
| Total L2 Cache |
5 MB |
| Processor Base Power |
60 W |
| Maximum Turbo Power |
89 W |
| Memory Specifications |
| Max Memory Size (dependent on memory type) |
128 GB |
| Memory Types |
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
|
| Max # of Memory Channels |
2 |
| Max Memory Bandwidth |
76.8 GB/s |
| Processor Graphics |
| Processor Graphics ‡ |
Intel® UHD Graphics 730 |
| Graphics Base Frequency |
300 MHz |
| Graphics Max Dynamic Frequency |
1.40 GHz |
| Graphics Output |
eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Execution Units |
24 |
| Max Resolution (HDMI)‡ |
4096 x 2160 @ 60Hz |
| Max Resolution (DP)‡ |
7680 x 4320 @ 60Hz |
| Max Resolution (eDP - Integrated Flat Panel)‡ |
5120 x 3200 @ 120Hz |
| DirectX* Support |
12 |
| OpenGL* Support |
4.5 |
| Multi-Format Codec Engines |
1 |
| Intel® Quick Sync Video |
Yes |
| Intel® Clear Video HD Technology |
Yes |
| # of Displays Supported ‡ |
4 |
| Device ID |
0x4692 |
| OpenCL* Support |
2.1 |
| Expansion Options |
| Direct Media Interface (DMI) Revision |
4.0 |
| Max # of DMI Lanes |
8 |
| Scalability |
1S Only |
| PCI Express Revision |
5.0 and 4.0 |
| PCI Express Configurations ‡ |
Up to 1x16+4, 2x8+4 |
| Max # of PCI Express Lanes |
20 |
| Package Specifications |
| Sockets Supported |
FCLGA1700
|
| Max CPU Configuration |
1 |
| Thermal Solution Specification |
PCG 2020C |
| TJUNCTION |
100°C |
| Package Size |
45.0 mm x 37.5 mm |
| Advanced Technologies |
| Intel® Gaussian & Neural Accelerator |
3.0 |
| Intel® Thread Director |
No |
| Intel® Deep Learning Boost (Intel® DL Boost) |
Yes |
| Intel® Optane™ Memory Supported ‡ |
Yes |
| Intel® Speed Shift Technology |
Yes |
| Intel® Turbo Boost Max Technology 3.0 ‡ |
No |
| Intel® Turbo Boost Technology ‡ |
2.0 |
| Intel® Hyper-Threading Technology ‡ |
Yes |
| Intel® Virtualization Technology (VT-x) ‡ |
Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ |
Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ |
Yes |
| Intel® 64 ‡ |
Yes |
| Instruction Set |
64-bit |
| Instruction Set Extensions |
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States |
Yes |
| Enhanced Intel SpeedStep® Technology |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel® Volume Management Device (VMD) |
Yes |
| Security & Reliability |
| Intel® AES New Instructions |
Yes |
| Secure Key |
Yes |
| Intel® OS Guard |
Yes |
| Execute Disable Bit ‡ |
Yes |
| Intel® Boot Guard |
Yes |
| Mode-based Execute Control (MBEC) |
Yes |
| Intel® Control-Flow Enforcement Technology |
Yes |
| Warranty |
3 Years |
| Note |
*** Features, Price, Specifications are subject to change without notice. |
